Stormcloud®

Stormcloud® is New Zealand’s most popular spouting style.

  • Versatile quarter-round profile
  • Clean, strong lines
  • Suits both traditional and contemporary homes
  • Available in a range of colours with matching RP80® downpipes



AVAILABLE IN A RANGE OF COLOURS



Why Marley Spouting?

15 year guarantee

We stand by our product, and back it for 15 years

Will not rust / corrode

Designed for NZ’s salt-laden coastal air

UV resistant

UV resistant to handle NZ’s harsh summer sun, high UV levels and long, hot days

100% Recyclable

Used spouting and downpipes can be returned to Marley for recycling

Made in NZ

Proudly made in New Zealand for over 40 years

Components

 PRODUCTSCODE

STORMCLOUD® SPOUTING
3m Length

MS1.3

STORMCLOUD® SPOUTING
5m Length

MS1.5

SPOUTING BRACKET

MS2

LH COMBINATION
STOPEND

MS3

RH COMBINATION
STOPEND

MS4

SPOUTING JOINER

MS5

EXPANSION JOINER

MS17

EXTERNAL ANGLE 90°

MS6

EXPANSION OUTLET
65mm

MS8.65

INTERNAL ANGLE 90°

MS7

EXPANSION OUTLET
80mm

MS8.80

DROPPER OUTLET
65mm

MC11.65

DROPPER OUTLET
80mm

MC11.80

DROPPER OUTLET
100 x 50mm

MC11.100.50

OUTLET STRAINER

RWST

SOLVENT WELDING CEMENT
180g Tube

MCS

GALVANISED NAILS
150 Per Packet

MCNAILS

BRACKET SCREWS FOR METAL FASCIA

SCREW.METAL
 PRODUCTSCODE

STORMCLOUD® SPOUTING
4m Length

MS1.4.BLK

SPOUTING BRACKET

MS2.BLK

LH COMBINATION
STOPEND

MS3.BLK

RH COMBINATION
STOPEND

MS4.BLK

SPOUTING JOINER

MS5.BLK

EXPANSION JOINER

MS17.BLK

EXTERNAL ANGLE 90°

MS6.BLK

EXPANSION OUTLET
65mm

MS8.65.BLK

INTERNAL ANGLE 90°

MS7.BLK

EXPANSION OUTLET
80mm

MS8.80.BLK

DROPPER OUTLET
65mm

MC.11.65.BLK

DROPPER OUTLET
80mm

MC11.80.BLK

OUTLET STRAINER

RWST

SOLVENT WELDING CEMENT
180g Tube

MCS.BLK

GALVANISED NAILS
150 Per Packet

MCNAILS

BRACKET SCREWS FOR METAL FASCIA

SCREW.METAL
 PRODUCTSCODE

STORMCLOUD® SPOUTING
4m Length

MS1.4.IRO

SPOUTING BRACKET

MS2.IRO

LH COMBINATION
STOPEND

MS3.IRO

RH COMBINATION
STOPEND

MS4.IRO

SPOUTING JOINER

MS5.IRO

EXPANSION JOINER

MS17.IRO

EXTERNAL ANGLE 90°

MS6.IRO

EXPANSION OUTLET
65mm

MS8.65.IRO

INTERNAL ANGLE 90°

MS7.IRO

EXPANSION OUTLET
80mm

MS8.80.IRO

DROPPER OUTLET
65mm

MC11.65.IRO

DROPPER OUTLET
80mm

MC11.80.IRO

OUTLET STRAINER

RWST

SOLVENT WELDING CEMENT
180g Tube

MCS.IRO

GALVANISED NAILS
150 Per Packet

MCNAILS

BRACKET SCREWS FOR METAL FASCIA

SCREW.METAL
 PRODUCTSCODE

STORMCLOUD® SPOUTING
4m Length

MS1.4.GYF

SPOUTING BRACKET

MS2.GYF

LH COMBINATION
STOPEND

MS3.GYF

RH COMBINATION
STOPEND

MS4.GYF

SPOUTING JOINER

MS5.GYF

EXPANSION JOINER

MS17.GYF

EXTERNAL ANGLE 90°

MS6.GYF

EXPANSION OUTLET
65mm

MS8.65.GYF

INTERNAL ANGLE 90°

MS7.GYF

EXPANSION OUTLET
80mm

MS8.80.GYF

DROPPER OUTLET
65mm

MC11.65.GYF

DROPPER OUTLET
80mm

MS11.80.GYF

OUTLET STRAINER

RWST

SOLVENT WELDING CEMENT
180g Tube

MCS.GYF

GALVANISED NAILS
150 Per Packet

MCNAILS

BRACKET SCREWS FOR METAL FASCIA

SCREW.METAL

Resources

Technical Details

Effective Cross Sectional Area: 5100mm2

Flow Capacity: 70 litres/minute

Material: uPVC (Unplasticised PVC)

Minimum Recommended Fall: 1:2000

Bracket System: Internal brackets. To be spaced at max 500mm centres (reduce to 300mm in high wind or snow prone areas). All Marley Spouting bracket systems create + maintain a 10mm gap between the fascia and the back face of the spouting to allow water to spill to the exterior of the building envelope (as recommended in BRANZ Technical Bulletin Issue 509, “Sizing Gutters and Downpipes”, Clause 4.01).

Spouting Capacity:

Rainfall Intensity*
(mm/hr)
405060708090100110120130140150
Maximum Catchment
Area per downpipe(m²)
1048470605246423835323028

* As per NZBC E1 – Surface Water, Rainfall Intensity equates to a 1 in 10 year storm and varies depending on geographic location. For example, 100mm/hr is a general rule of thumb for the Auckland region however please refer to hirds.niwa.co.nz for current rainfall intensity specific to your location.

Certified for use with potable water? Yes (certified to AS/NZS 4020)

Environmental certification: ISO 14001, BEP certification

Compatible Marley Downpipe systems: RP80® 80mm Round DownpipeRP65® 65mm Round Downpipe, Rectangular downpipe

Required Glue: Marley MCS® Solvent Cement (see component list for colour match/code)

INSTALLATION

Marley spouting and downpipes are intuitively designed as a modular system, making repair and replacement much simpler. There is a technical element to installing Marley spouting so if you are unsure, Marley recommends you seek advice from a trade professional. Alternatively for a step by step DIY guide, please click here.

STORAGE AND HANDLING

If storing Marley uPVC spouting and downpipe systems for a long period of time, the product should be kept in its original polyethylene sleeving and the fittings kept in their cartons. Both should be stored inside a building, out of direct sunlight.

Furthermore:

  • Profiles should be well supported and stored on a flat surface to avoid deformation. Avoid stacking too many bundle packs to prevent overloading. A maximum of 4 packs high is recommended.
  • Fittings supplied in cartons should be stored under cover in a cool dry place and remain packed until required for installation.

Solvent welding MCS must be securely stored in a cool place, out of direct sunlight and away from any heat source. If the only option is to store the spouting and downpipe for long periods in strong sunlight, they should also be covered with a light coloured opaque sheet.
